ROGA -instruments
ROGA麦克风 ROGA传感器 ROGA噪音分析仪 ROGA数据记录仪 ROGA前置放大器等
中文名： ROGA
国家：德国
网站：roga-instruments.com
ROGA -instruments -品牌介绍
ROGA Instruments 的测量系统为您提供广泛的测量和数据分析系统。
除其他项目外，我们还为工业和教育客户具有挑战性的测量、观察和分析任务开发硬件和软件交钥匙解决方案。
在这里，您可以找到用于声音测量技术和振动测量技术、模态分析、通用测量技术和特殊应用、声音分析、振动分析、长期高速测量数据采集、安全测量数据存储、实时分析、振动监测、控制应用和控制应用以及机器控制的系统解决方案。
ROGA-Instruments 还生产 IEPE 麦克风和数字 IEPE USB 传感器调节器。
ROGA-Instruments是一家专注于工业测量和控制系统解决方案的德国公司，提供多种工业测量仪器和控制系统，广泛应用于各种工业领域。
主要产品和服务
ROGA-Instruments的主要产品包括：
便携式数据采集系统（如Plug.n.DAQ Lite）
台式数据采集系统（如RogaDAQ 16）
电网分析仪（如RogaDAQ2）
分析软件（如DASYLab）
可视化软件（如FlexPro）
测量麦克风（如MI-17 series）
电流预放大器（如MP40）
三轴加速度传感器
声学振动传感器
压缩型负荷传感器12
应用领域和市场定位
ROGA-Instruments的产品广泛应用于以下领域：
振动测量
声音测量
电流预放大
加速度测量
负荷测量
这些产品帮助用户进行精确的数据采集和分析，适用于各种工业环境和科研需求。
ROGA -instruments -主要产品
ROGA麦克风 ROGA传感器 ROGA噪音分析仪 ROGA数据记录仪 ROGA前置放大器等
ROGA -instruments -系列参数
MI19 and MI21 microphone sleeve adapter
from 1/4″ inner diameter to 1/2″ outer diameter.
POM material to ensure galvanic isolation to prevent ground and earth loops
POM-MI17RG50
MI17 and RG-50 microphone sleeve adapter to 1/2″ outer diameter.
POM material to ensure galvanic isolation to prevent ground and ground loops
MicCAL
Microphone Calibration Fee for ROGA Instruments microphones
MI15 | MI17 | MI18 | MI19 | MI21| RG-50 | MP30| MP40
After successful factory calibration, the microphone is returned to
the customer with our factory calibration certificate.
MicREP
Microphone Repair Fee for ROGA Instruments microphones
MI15 | MI17 | MI18 | MI19 | MI21| RG-50
After successful repair and factory calibration, the microphone is returned to the
customer with our factory calibration certificate.
WS-RG-40
1/4″ microphone windscreen Ø 40 mm
MI19
MI19; ¼” electret microphone
for industrial applications
Sensitivity 50 mV/Pa
Constant current supply 2-8 mA
BNC connector
Polar pattern: omnidirectional
Class 1 frequency response in accordance with IEC 61672
20 Hz – 20 kHz
calibration sheet included Sensitivity & Frequency Response
Inherent noise 27 dBA
SPL Max 130 dB
HS Code 85181000
MI19SW
IP55 splash water resistant
¼” electret microphone
for industrial applications
Sensitivity 50 mV/Pa
Constant current supply 2-8 mA
BNC connector
Polar pattern: omnidirectional
Class 1 frequency response in accordance with IEC 61672
20 Hz – 20 kHz
calibration sheet included Sensitivity & Frequency Response
Inherent noise 27 dBA
SPL Max 130 dB
HS Code 85181000
RG-50HL
High SPL Microphone e.g. shooting noise
WS3F Free-field IEC 61094-5
Total length: 95 mm
Sensitivity 10 mV/Pa
constant current Supply 2-20 mA
BNC connection
Polar pattern: omnidirectional
Frequency response:
5 Hz – 4 kHz: ± 1 dB
4 kHz – 30 kHz: ± 1.5 dB
factory calibration certificate included
measuring range up to SPL 144 dBRMS / 150 dB peak
HS Code 85181000
MK342 E
+
MV310
Set
1/4″ microphone with constant pressure frequency response
WS3P according to IEC 61094-4
Pressure
3.5Hz to 70kHz
60dB(A) to 186dB
pre-polarized
HS Code 85181000
MI21
MI21; ¼” electret condenser microphone
Splash Water Proof IP55
Sensitivity 50 mV/Pa / ± 1.0 dB
CCP IEPE supply 2-6 mA
BNC connector
Polar pattern: omnidirectional
Frequency response IEC 61094-5
20 Hz – 4 kHz: ± 0.5 dB
4 kHz – 20 kHz: ± 1.5 dB
corresponds to class 1
Calibration sheet included Sensitivity & Frequency Response
Inherent noise 26 dB(A)
SPL Max 130 dB
HS Code 85181000
MI17
MI17; 1/4″ IEPE microphone,
Sensitivity 50 mV/Pa,
constant current supply 2-8 mA
BNC connection
Frequency response: Class 1 – IEC 61094-5
20 Hz – 4 kHz: ± 0.5 dB
4 kHz – 20 kHz: ± 1.5 dB
free field, corresponds to class 1
including individual Calibration sheet
(sensitivity & frequency response)
Inherent Noise 26 dB (A)
Download MI17 PDF
HS Code 85181000
MI17SW
MI 17SW; 1/4″ IEPE microphone
Splash Water Proof IP55
Sensitivity 50 mV/Pa,
constant current supply 2-8 mA
BNC connection
Frequency response:
20 Hz – 4 kHz: ± 0.5 dB
4 kHz – 20 kHz: ± 1.5 dB
free field, corresponds to class 1 IEC 61094-5
including individual Calibration sheet
(sensitivity & frequency response)
Inherent Noise 26 dB (A)
HS Code 85181000
RG-50
RG-50; 1/4″ IEPE free field microphone
Sensitivity 50 mV/Pa
constant current supply 2- 20mA
BNC connection
Frequency response
5 Hz – 4 kHz: ± 0.5 dB
4 kHz – 30 kHz: ± 1.5 dB
free field, corresponds to class 1 IEC 61094-5
including individual Calibration
sheet (sensitivity & frequency response)
Inherent Noise 26 dB (A)
HS Code 85181000
RG-50SW
RG-50SW; 1/4″ IEPE Free-field microphone
Sensitivity 50 mV / Pa
constant current supply 2- 20mA
BNC connection
Splash Water Proof IP55
Frequency response
5 Hz – 4 kHz: ± 0.5 dB
4 kHz – 30 kHz: ± 1.5 dB
free field, corresponds to class 1 IEC 61094-5
including individual Calibration
sheet (sensitivity & frequency response)
Inherent Noise 26 dB (A)
HS Code 85181000
MicCAL
Microphone Calibration Fee for all ROGA Instruments microphones.
After successful factory calibration, the microphone is returned to the customer with our factory calibration certificate.
WS-RG-80
1/2″ measurement microphone wind screen Ø 80 mm diameter
MP30
MP30 Microphone Set
Prepolarised Microphone Capsule
with Microphone Preamplifier
1/2″ IEPE Free-field microphone
Sensitivity 40 mV/Pa
constant current supply 2- 20mA
BNC connection
Polar pattern: omnidirectional
Frequency response
4 Hz ~ 10 Hz ± 1.5 dB
10 Hz – 4 kHz: ± 0.5 dB
4 kHz – 20 kHz: ± 2.5 dB
free field, corresponds to class 1
including individual Calibration
sheet (sensitivity & frequency response)
Measuring Range: 16 dB(A) to 135 dB
HS Code 85181000
MP30-231
MP30-231 Microphone Set
Prepolarised Microphone Capsule
with Microphone Preamplifier
1/2″ IEPE difussefield microphone
Sensitivity 50 mV/Pa
constant current supply 2- 20mA
BNC connection
Polar pattern: omnidirectional
Frequency response
3.5 Hz – 16 kHz: ± 2 dB
including individual Calibration
sheet (sensitivity & frequency response)
Measuring Range: 15 dB(A) to 135 dB
HS Code 85181000
MP30-Infra
1/2″ microphone for infrasonic low frequency applications
WS2F according to IEC 61094-4
Free field
0.5 Hz to 20 kHz
15 dBA to 135 dB
pre-polarized
1/2″ microphone preamplifier MP30 included
HS Code 85181000
MP40
MP40 Set
1/2 ” condenser microphone
WS2F (DIN IEC 61094-4)
Frequency range:
1.5 Hz – 3.5 Hz: ± 1.5 dB
3.5 Hz – 4 kHz: ± 0.5 dB
4 kHz – 20 kHz: ± 1.5 dB
Free-field
Including preamplifier PA-01
Dynamic range 16 dB(A) -135dB
IEPE Constant Current powered
Sensitivity: 50 mV / Pa
Download MP-40 PDF
HS Code 85181000
MM210
1/2″ microphone for general applications
WS2F according to IEC 61094-4
Free field
50 mV/Pa
3.5 Hz to 20 kHz
15 dBA to 146 dB
pre-polarized
1/2″ microphone preamplifier MV210 included
HS Code 85181000
MMS 214
Low noise microphone MMS 214 has a particularly low inherent noise level and is designed for acoustic measurements of low sound pressure levels close to the threshold of human hearing
HS Code 85181000
1/2″
Microphone
capsules
1/2” measuring microphone capsules with different properties. From infrasound to ultrasonic models
HS Code 85181000
–
Model
USB Microphone Systems Class 1 WS2F
Price
FairTECH
ROGA Instruments products are free from planned obsolescence, technically accessible, durable and repairable.
iSV1611-Infra
1/2″ USB microphone for infrasound applications
WS2F according to IEC 61094-4
Free field
1 Hz to 20 kHz
15 dBA to 135 dB
pre-polarized
1/2″ USB microphone preamplifier iSV1611 included
HS Code 85181000
iSV1611-Ultra
1/4″ USB microphone for ultrasonic applications
MK 301 E Microphone Capsule
WS3F according to IEC 61094-4
Free field
5 Hz to 80 kHz
35 dBA to 168 dB
pre-polarized
1/2″ USB microphone preamplifier iSV1611 included
HS Code 85181000
KS901B10
KS901B100
IEPE accelerometer
Low-cost IEPE accelerometers for integration
into machines and instruments
Frequency response 0.35 Hz-28 kHz
Sensitivity 10 mV/g
or
100 mV/g
Mass 5.2 grams
Measuring range 500 g
Download KS901B1x PDF
KS76C
KS77C
IEPE accelerometer
General purpose shear-type accelerometer
Two sensitivity versions
Low sensitivity to temperature transients
Low influence of base bending effects
IEPE compatible output allows long cables
High linear band width up to 37 kHz
Low noise, high resolution
Sturdy stainless steel housing
M5 mounting thread in base
KS78C10
or
KS78C100
KS78C10 | 100; IEPE accelerometer
Contains digital memory for sensor data (TEDS)
Frequency response 0.65 Hz-23 kHz
Sensitivity 10 mV/g or 100 mV/g
Mass 11.2 grams
Measuring range: 500 g or 50 g
KS84.100
Accelerometer Magnet Mount
Rugged stainless steel case
With insulated case avoiding ground loop problems
Double shielding for best EMI protection
Protection grade IP67 by double sealing against humidity
M12 connector for easy on-site installation,
improved replacement for obsolete MIL-C-5015 connectors
Economic price
Successor model of KS80D
KS96B10
KS96B100
KS96B10 | KS96B100 IEPE miniature accelerometer
Frequency response 0.2 Hz-18 kHz
Sensitivity 10 mV/g | 100 mV/g
Mass 3.2 g Measuring range ± 500 or ± 60 g
KS97B10
KS97B100
KS97B10 | KS97B100 IEPE miniature accelerometer
Frequency response 0.2 Hz-18 kHz
Sensitivity 10 mV/g | 100 mV/g
Mass 3.2 g Measuring range ± 500 or ± 60 g
KS98B10
KS98B100
KS98B10 | KS98B100 IEPE miniature accelerometer
Frequency response 0.2 Hz-18 kHz
Sensitivity 10 mV/g | 100 mV/g
Mass 3.2 g Measuring range ± 500 or ± 60 g
KS91C/01
IEPE accelerometer
Miniature Accelerometer For lightweight targets
– KS91C in subminiature version –
KS91C with IEPE voltage output –
– High dynamic range
– High resonant frequency
– Low temperature dependence
– Pluggable cables
– KS91C with insulated bottom against ground loops
Frequency response 0.3 Hz-37 kHz
Sensitivity 10 mV/g
Mass 1.3 grams
Measuring range 600 g
Transducer with accessory case:
contents: cable 009-SUB-BNC-1.5,
adhesive wax 002,
instant adhesive 038,
removal tool 039, identification sheet
KS48C/01
High Sensitivity Accelerometer @ 1000 mV/g
Suited for seismic measurement and building vibration
particularly at low frequencies
Extremely sensitive piezo system provides
excellent resolution and lowest noise
KS48C with IEPE voltage output
KS48C with protection grade IP67
Delivery version with accessories kit
– 208: Rare earth magnetic base; M8; D30; 120 °C
– 206: Screwed insulating flange; 2 x M8; D30; 110 °C
– 043: Mounting stud; M8 x 10
– 085-B713G-BNC-5: Cable for IEPE sensors;
5 m; Binder 713; straight; female. to BNC; 80 °C; D5
KB12VD
High Sensitivity Accelerometer @ 10 V/g
Suitable for seismic measurements and structural investigations
at low frequencies
– Highly sensitive sensor system without internal amplification
– thus excellent resolution and lowest noise
– KB12VD with particularly good sensitivity/ mass ratio
– KB12VD with air-damped resonance and
overload protection by friction coupling
– KB12VD and KS48C with IEPE voltage output
Frequency response 0.05 Hz – 260 Hz
Sensitivity 10 000 mV/g
Mass 150 grams
Measuring range ± 0.6 g
Triaxial Accelerometer
Price
KS903B10/01
or
KS903B100/01
IEPE accelerometer
Small dimensions
Excellent phase response
High resolution
Low temperature coefficient
Includes electronic data sheet (TEDS)
Suitable for modal and structural analysis
Download KS903B1xx PDF
KS813B Set
Inustrial Triaxial Accelerometer Set
Rugged industrial design
Protection grade IP67
Insulated base against ground loops
Trough hole for easy attachment
088-B718G-B711-5: Cable with connector
Binder 711, 5 m, for adapter 034
034-B711f-BNC: Adapter from connector
Binder 711 to 3 BNC connectors
ROGA -instruments-热销型号
| 欧拓华科技（东莞）有限公司 | ROGA HR-12 PC Card |
| 欧拓华科技（东莞）有限公司 | ROGA EI. Stethoscope ES-12 |
| 欧拓华科技（东莞）有限公司 | ROGA PIug.n.DAQ |
| 欧拓华科技（东莞）有限公司 | ROGA Plug.n.DAQ Lite |
| 欧拓华科技（东莞）有限公司 | ROGA RogaDAQ1 |
| 欧拓华科技（东莞）有限公司 | ROGA RogaDAQ4 |
| 欧拓华科技（东莞）有限公司 | ROGA RogaDAQ16 |
| 欧拓华科技（东莞）有限公司 | ROGA RogaDAQ2 |
| 欧拓华科技（东莞）有限公司 | ROGA 3019A |
| 欧拓华科技（东莞）有限公司 | ROGA 3019A1 |
| 欧拓华科技（东莞）有限公司 | ROGA 3058A |
| 欧拓华科技（东莞）有限公司 | ROGA 3059A |
| 欧拓华科技（东莞）有限公司 | ROGA 3063B |
| 欧拓华科技（东莞）有限公司 | ROGA 3148D |
| 欧拓华科技（东莞）有限公司 | ROGA 3166B |
| 欧拓华科技（东莞）有限公司 | ROGA 3166B1 |
| 欧拓华科技（东莞）有限公司 | ROGA 3176B |
| 欧拓华科技（东莞）有限公司 | ROGA 3176B1 |
| 欧拓华科技（东莞）有限公司 | ROGA 3184E |
| 欧拓华科技（东莞）有限公司 | ROGA 3185D |
| 欧拓华科技（东莞）有限公司 | ROGA 3187D |
| 欧拓华科技（东莞）有限公司 | ROGA 3191A |
| 欧拓华科技（东莞）有限公司 | ROGA 3191A1 |
| 欧拓华科技（东莞）有限公司 | ROGA 3192A |
| 欧拓华科技（东莞）有限公司 | ROGA 3202A |
| 欧拓华科技（东莞）有限公司 | ROGA 3202A1 |
| 欧拓华科技（东莞）有限公司 | ROGA 3202A2 |
| 欧拓华科技（东莞）有限公司 | ROGA 3202A3 |
| 欧拓华科技（东莞）有限公司 | ROGA MI-17 |
| 欧拓华科技（东莞）有限公司 | ROGA IH-01 |
| 欧拓华科技（东莞）有限公司 | ROGA IH-02 |
| 欧拓华科技（东莞）有限公司 | ROGA IH-05 |
| 欧拓华科技（东莞）有限公司 | ROGA IH-10 |
| 欧拓华科技（东莞）有限公司 | ROGA IH-5 |
| 欧拓华科技（东莞）有限公司 | ROGA 1203V1 |
| 欧拓华科技（东莞）有限公司 | ROGA 1203V2 |
| 欧拓华科技（东莞）有限公司 | ROGA 1203V3 |
| 欧拓华科技（东莞）有限公司 | ROGA 1203V4 |
| 欧拓华科技（东莞）有限公司 | ROGA 1203V5 |
| 欧拓华科技（东莞）有限公司 | ROGA 1050V1 |
| 欧拓华科技（东莞）有限公司 | ROGA 1050V2 |
| 欧拓华科技（东莞）有限公司 | ROGA 1050V3 |
| 欧拓华科技（东莞）有限公司 | ROGA 1050V4 |
| 欧拓华科技（东莞）有限公司 | ROGA 1050V5 |
| 欧拓华科技（东莞）有限公司 | ROGA 1050V6 |
| 欧拓华科技（东莞）有限公司 | ROGA 1051V1 |
| 欧拓华科技（东莞）有限公司 | ROGA 1051V2 |
| 欧拓华科技（东莞）有限公司 | ROGA 1051V3 |
| 欧拓华科技（东莞）有限公司 | ROGA 1051V4 |
| 欧拓华科技（东莞）有限公司 | ROGA 1051V5 |
| 欧拓华科技（东莞）有限公司 | ROGA 1051V6 |
| 欧拓华科技（东莞）有限公司 | ROGA 1060V1 |
| 欧拓华科技（东莞）有限公司 | ROGA 1060V2 |
| 欧拓华科技（东莞）有限公司 | ROGA 1060V3 |
| 欧拓华科技（东莞）有限公司 | ROGA 1060V4 |
| 欧拓华科技（东莞）有限公司 | ROGA 1060V5 |
| 欧拓华科技（东莞）有限公司 | ROGA 1060V6 |
| 欧拓华科技（东莞）有限公司 | ROGA 1061V1 |
| 欧拓华科技（东莞）有限公司 | ROGA 1061V2 |
| 欧拓华科技（东莞）有限公司 | ROGA 1061V3 |
| 欧拓华科技（东莞）有限公司 | ROGA 1061V4 |
| 欧拓华科技（东莞）有限公司 | ROGA 1061V5 |
| 欧拓华科技（东莞）有限公司 | ROGA 1061V6 |
| 欧拓华科技（东莞）有限公司 | ROGA DR-600 |
| 欧拓华科技（东莞）有限公司 | ROGA PA201 Smart |
| 欧拓华科技（东莞）有限公司 | ROGA PA201-1CH |
| 欧拓华科技（东莞）有限公司 | ROGA PA201-2CH |
| 欧拓华科技（东莞）有限公司 | ROGA PA201-3CH |
| 欧拓华科技（东莞）有限公司 | ROGA AS-11 |
| 欧拓华科技（东莞）有限公司 | ROGA AS-10 |
| 欧拓华科技（东莞）有限公司 | ROGA 111A01 |
| 欧拓华科技（东莞）有限公司 | ROGA 111A02 |
| 欧拓华科技（东莞）有限公司 | ROGA 211A01 |
| 欧拓华科技（东莞）有限公司 | ROGA 211A02 |
| 欧拓华科技（东莞）有限公司 | ROGA 211A05 |
| 欧拓华科技（东莞）有限公司 | ROGA 211A10 |
| 欧拓华科技（东莞）有限公司 | POM-MI1921 |
德国ROGA -instruments代理
德国ROGA -instruments原装进口
德国ROGA -instruments中国
德国ROGA -instruments全系列官网快速报价
德国ROGA -instruments表格
德国ROGA -instruments总代
德国ROGA -instruments优势
德国ROGA -instruments现货
德国ROGA -instruments选型
德国ROGA -instruments介绍
原装德国进口德国ROGA -instruments
德国ROGA -instruments批发
德国ROGA -instruments
德国ROGA -instruments简介
德国ROGA -instruments说明
德国ROGA -instruments官方网站
